NewMar SilverLeaf RV-C Control System - FLOOR HEAT WITH 4 TIME SCHEDULE; SCREEN 1: AM SETTINGS

Page 28
FLOOR HEAT with 4 Time Schedule Screen 1 of 3
The Floor Heat Configuration Screen is accessed
by pressing the Floor Heat Configuration Button
located on the Features Configuration Screen.
This screen is only applies to systems with the
Floor Heat option.
These selections set the 2 time zones floor heat
settings displayed on the “Floor” Screen.
Depending on the HMS360 Touch Screen
Display Software Version, this screen or a
similar screen, may be located under the
Climate Configuration Screens, not under the
Floor Heat Configuration Screens
This screen allows you to change the following
settings:
AM/On Time Setting
Select using the Up / Down Arrows
AM/Off Time Setting
Select using the Up / Down Arrows
AM/On Setting Floor Heat Setting
Select using the Up / Down Arrows
FLOOR HEAT with 4 Time Schedule Screen 2 of 3
The Floor Heat Configuration Screen is accessed
by pressing the Floor Heat Configuration Button
located on the Features Configuration Screen.
This screen is only applies to systems with the
Floor Heat option.
These selections set the 2 time zones floor heat
settings displayed on the “Floor” Screen.
Depending on the HMS360 Touch Screen
Display Software Version, this screen or a
similar screen, may be located under the
Climate Configuration Screens, not under the
Floor Heat Configuration Screens
This screen allows you to change the following
settings:
PM/On Time Setting
Select using the Up / Down Arrows
PM/Off Time Setting
Select using the Up / Down Arrows
PM/On Setting Floor Heat Setting
Select using the Up / Down Arrows
