NewMar SilverLeaf RV-C Control System - FLOOR HEAT WITH 2 TIME SCHEDULE; SCREEN 1: DAY;NIGHT SETTINGS

Page 27
FEATURES FLOOR HEAT W/SCHEDULING CONFIGURATION SCREENS
FLOOR HEAT with 2 Time Schedule Screen 1 of 2
The Floor Heat Configuration Screen is accessed
by pressing the Floor Heat Configuration Button
located on the Features Configuration Screen.
This screen is only applies to systems with the
Floor Heat option.
These selections set the 2 time zones floor heat
settings displayed on the “Floor” Screen.
Depending on the HMS360 Touch Screen
Display Software Version, this screen or a
similar screen, may be located under the
Climate Configuration Screens, not under the
Floor Heat Configuration Screens
This screen allows you to change the following
settings:
Day Begin Time Setting
Select using the Up / Down Arrows
Night Begin Time Setting
Select using the Up / Down Arrows
Day Setting Floor Heat Setting
Select using the Up / Down Arrows
Night Setting Floor Heat Setting
Select using the Up / Down Arrow
FLOOR HEAT with 2 Time Schedule Screen 2 of 2
The Floor Heat Configuration Screen is accessed
by pressing the Floor Heat Configuration Button
located on the Features Configuration Screen.
This screen is only applies to systems with the
Floor Heat option.
These selections set the floor heat zone names
displayed on the “Floor” Screen.
Depending on the HMS360 Touch Screen
Display Software Version, this screen or a
similar screen, may be located under the
Climate Configuration Screens, not under the
Floor Heat Configuration Screens
This screen allows you to change the following
settings:
Floor 1 Name Set to Front
Select using the Up / Down Arrows
Floor 2 Name Set to Mid
Select using the Up / Down Arrows
Floor 3 Name Set to Rear
Select using the Up / Down Arrows
