Newmar SilverLeaf Module Configuration Data & Screens
HMS360 Monitor
TM229 (TM220 Series) Tile Heat
Function
Setting
Function
Setting
Block Heater Instance
1
OEM Identifer
2
Air Conditioner Model
1
Ambient Temperature Instance
249
TM250 Load Manager
3 ACs
Zones
1,2 &4
Zone 1 Cool Instance
1
Load1 Load Type
5
Zone 2 Cool Instance
2
Zone 3 Cool Instance
0
TM510 (Dometic)
Zone 4 Cool Instance
4
Secondary Heat Mode
0
Zone 1 Heat Instance
1
Heat Pump Temp Limit
40
Zone 2 Heat Instance
2
Outside Air Temp Instance
249
Zone 3 Heat Instance
166
Secondary Heat Boost Level
5
Zone 4 Heat Instance
4
Zone 1 Instance
1
Zone
Temp
Display
Source
Zone 1 Temp Instance
1
Zone 1 Secondary Heat Instance
164
Zone 2 Temp Instance
2
Zone 1 Compressor Instance
2
Zone 3 Temp Instance
248
Zone 1 Fan Instance
3
Zone 4 Temp Instance
4
Zone 2 Instance
2
Primary
Source
3 Heat
Pumps
Zone 1 Furnace Instance
1
Zone 2 Secondary Heat Instance
165
Zone 2 Furnace Instance
2
Zone 2 Compressor Instance
4
Zone 3 Furnace Instance
0
Zone 2 Fan Instance
5
Zone 4 Furnace Instance
4
Zone 3 Instance
0
Secndry
Heat
Source
3 Oasis
Zone 1 Sec Heat Instance
164
Zone 3 Secondary Heat Instance
0
Zone 2 Sec Heat Instance
0
Zone 3 Compressor Instance
0
Zone 3 Sec Heat Instance
166
Zone 3 Fan Instance
0
Zone 4 Sec Heat Instance
167
Zone 4 Instance
4
Zone 4 Secondary Heat Instance
167
Zone 4 Compressor Instance
6
Zone 4 Fan Instance
7
