VMC 1100 User Manual
Chapter 1: Product Introduction
Item Function Description
1 Function Key There are five buttons and 5 function keys on VMC 1100.
2 Speaker VMC 1100 includes the dual speaker; the specification is 2W/ 8Ω.
3 Internal Mic-in Built-in microphone, does not need any monophonic input from an external microphone.
4 Light Sensor Light sensors can adjust a display’s backlight, which improves the power savings and optimizes the display’s viewability.
5 Indicator
• Power mode
No power, no light
Initial power-on: Green indicator stays lit around 2~3 seconds.
Boot loader or BIOS status: Orange indicator blinking for 1 second.
System login in status: Green indicator blinking for 1 second.
All process ready in system, ready for customer use: Green indicator stays lit.
• Storage: Green, data is being read from or written to the storage driver.
• WWAN: Green, the wireless WAN is on, and the radio link is ready for use. Blinking green, data is being transmitted.
6 Power Key
• When the ignition is from “low” to “high”, VMC will turn on automatically.
• When the ignition is “high”, press the power button 5 seconds to turn on/off VMC.
• When the ignition is from “high” to “low”, VMC will turn off automatically.
• When the ignition is “low”, pressing the power button will not turn on VMC.
• When you press it for 1 second, the display will turn on/off.
7, 8
Volume key/
Brightness Control
key
Volume Up/ Down (Default): Audio volume can be adjusted in 10 levels using the buttons.
Brightness Control:
There are two modes for Brightness Control: Manual Mode and Auto Mode.
In Manual Mode, LCD brightness can be adjusted in 10 levels using the “+” or “-” buttons.
9 Reset Hardware reset.
10
Left Side I/O with
Special Screw Lock
VMC 1100
• SIM card slot
• Micro SD slot
