VMC 1100 User Manual

Chapter 1: Product Introduction

Item Function Description

11 Left Side I/O

VMC 1100

• USB 3.0

• Mic-in

• Line-out

Wi-Fi Antenna

Connector

• The 2 external SMA type antenna mounting connectors are used to connect the antenna to a WLAN module and

Bluetooth.

GPS Antenna

Connector

• The external SMA type antenna mounting connector is used to connect the antenna to a GPS module.

WWAN Antenna

Connector

• The external SMA type antenna mounting connector is used to connect the antenna to a WWAN module.

15 Multi I/O Port

DB15 female connector with GPIO/ADC/PWM.

Pin Description

1 Speed 1

2 Speed 2

3 ADC 0

4 ADC 1

5 A_GND

6 GPI 1

7 GPI 2

8 MDI 1 (for tracker, SOS)

Pin Description

9 GPO 1

10 GPO 2

11 MDI 2 (for tracker, release KEY)

12 DR GPS_IPPS

13 DR GPS_ODO

14 DR GPS_DIR

15 GND
