Appendix A: I/O Address Function
6. WDT
I/O port: 0EE5H
Bit3: WDT DISABLE\ENABLE
0: DISABLE(*)
1: ENABLE
BIT 2, 1, 0: time setting
BIT2~0 Time(sec)
000 1(*)
001 2
010 4
011 8
100 16
101 32
110 64
111 128
Auto clear WDT timer when read/write I/O port 0EE5H.
7. Onboard Module Disable/Enable(1)
I/O port : 0EE6H
Bit0: 3.5G MODULE
0: DISABLE
1: ENABLE (*)
Bit1: WLAN MODULE
0: DISABLE
1: ENABLE(*)
Bit2: EXTERNAL +12V power
0: DISABLE
1: ENABLE (*)
Bit3: By Pass Car battery power
0: DISABLE
1: ENABLE(*)
Bit4: Wake on 3.5G MODULE
0: DISABLE(*)
1: ENABLE
