Appendix A: I/O Address Function
Bit5: Wake on RTC MODULE
0: DISABLE(*)
1: ENABLE
Bit6: Power on/off CAN BUS MODULE
0: OFF
1: ON (*)
Bit7: Status of COM PORT
0: CAN BUS(*)
1: MCU Download
8. Delay Time Setting
I/O port : 0EE7H
Bit7: Power On Delay
0: DISABLE(*)
1: ENABLE
Bit6: Power Off Delay
0: DISABLE(*)
1: ENABLE
Delay On Time Setting
BIT5~3 Time
000 10 sec
001 30 sec
010 1 min
011 5 min
100 10 min
101 15 min
110 30 min
111 1 hour
BIT5~3 Time
000 10 sec
001 30 sec
010 1 min
011 5 min
100 10 min
101 15 min
110 30 min
111 1 hour
Delay Off Time Setting
