2 USB-Link™ Installation and Setup Manual
Chapter 1 • Introducing the USB-Link™
Product Specifications
The USB-Link™ is configured with the following specifications:
Feature Data
Physical Dimensions 5.86" x 3.02" x 1.78"
(149 mm x 77 mm x 45 mm)
Weight 4.6 oz. (0.13 kg)
Power Requirements 10 - 32 VDC @ 350 mA maximum
Operating Temperature 0 to +70 °C
Vehicle Protocols Supported • J1708/J1587
• J1939
• CAN (125K, 250K, or 500K)
(Dual CAN supported)
• J2284 CAN (125K, 250K, or
500K)
• ALDL Pass-through
• ALDL 8192
• ALDL 9600
•OBDII
• ISO 9141
• ISO 14230 (KWP2000)
• J1850 (PWM, VPM, or Allison)
• J1708
• IESCAN (required for Allison)
USB Communication USB Device, version 1.1
Wireless Communication Bluetooth
Class 1 adapter (up to
100 m range)
Wired Communication USB cable 15 ft. (5 m) maximum
PC Driver TMC RP1210A compliant
Vehicle Connector DB15F
USB Connector Type B jack
