- Step 8: Setting Up Diagnostic PC Applications
USB-Link™ Installation and Setup Manual 71
6 Click Next. The screen displays with the “Connection Name.”
—If you want to change the name in the Connection Name box, type in the
desired name.
7 Click
Next.
The screen prompts you to indicate whether you want to make this connec-
tion active or set up another connection.
8 Click on the first check box (
) (labeled “To make this connection active...”).
9 Click
Finish.
Detroit Diesel Diagnostic Link
NOTE:
i Complete the steps in the following procedure before attempting to run this
application.
1 From the PC’s desktop, click
Start then select Programs
4
Detroit Die-
sel
4
Options.
2 Click
Next>.
3 Select the Local Communication Interface by clicking on the arrow of the drop-
down list and pointing to the appropriate protocol (i.e., USB-Link J1708 or BT
USB-Link J1708).
4 Click
Next>.
5 Click
Finish.
Eaton Service Ranger
1 From the PC’s desktop, click Start then select Programs
4
Service
Ranger
4
Service Ranger.
The application screen appears.
2 On the
Service Ranger main menu, click on the Utilities menu, then select
View/Change Communications Settings.
The
Communications Hardware screen appears.
3 Click on USB-Link J1708, then click
OK.
