NEXIQ Technologies USB-Link - International INTUNE; International Master Diagnostics (3 BX, DLC, DLC II); Meritor WABCO ABS

72 USB-Link™ Installation and Setup Manual
Chapter 3 • Preparing to Use the USB-Link™
International INTUNE
1 From the PC’s desktop, click Start then select Programs
4
Vehicle Diagnos-
tics
4
INTUNE.
The
INTUNE application screen appears.
2 Click on the F
ile menu, then select Settings
4
Com Device... .
The screen prompts you to enter a communication DLL.
3 Click on
NEXIQ (NNT, Inc.) USB-Link, then click OK.
The screen prompts you to select a communication device.
4 Click on USB-Link J1939, then click
OK.
International Master Diagnostics (3BX, DLC, DLC II)
1 From the PC’s desktop, click Start then select Programs
4
Vehicle Diagnos-
tics
4
MD32 3BX (or DLC, or DLC II).
The application
screen appears.
2 Click on F
ile, then choose MD Settings
4
Com Device... .
A new screen appears, prompting you to select a communications device.
3 Click on
NEXIQ (NNT, Inc.) USB-Link, then click OK.
The screen displays a new list of options.
4 Click on USB-Link J1708, then click
OK.
Meritor WABCO ABS
1 From the PC’s desktop, click Start then select Programs
4
Meritor
WABCO
4
Meritor WABCO PC Diagnostics.
The application
screen appears.
2 Click on the S
ystem Setup menu item, then select COM Port.
The
Device Settings screen appears.
3 Under Vendor, click on the drop-down list box, then select
NEXIQ (NNT, Inc.) USB-Link.
4 Under Device, click on the drop-down list box, then select USB-Link J1708.
5 Click OK.
