68 USB-Link™ Installation and Setup Manual
Chapter 3 • Preparing to Use the USB-Link™
Step 8: Setting Up Diagnostic PC Applications
The diagnostic applications supported by the USB-Link™ use varying methods of
vehicle communication device selection. This section provides instructions for
configuring some of the PC diagnostic applications currently available for use with
the NEXIQ USB-Link™.
NOTE:
i The instructions provided here are based on the application settings at the
time this guide was developed.
NOTE:
i If you need assistance setting up these diagnostic PC applications, con-
tact NEXIQ Technical Support at 1-800-639-6774, or visit us online at
http://www.nexiq.com/support.
Allison DOC™ for Fleets (1000/2000)
1 From the PC’s desktop, click Start then select Programs
4
Allison Trans-
mission
4
Allison DOC 1K2K Lite.
The
Allison Transmission screen appears.
2 Click
Connect to Vehicle.
The Transmission Connect/Disconnect screen appears.
3 Click on the radio button (
) next to the Transmission Type field, then select
the desired transmission type.
4 Click on the next to the Vendor field, then select NXULNK32.
5 Click on the next to the Protocol field, then select J1939.
6 Click on the next to the Device field, then select USB-Link J1939 if con-
nection is wired; select BT USB-Link J1939 if the connection is wireless.
7 Click
Connect.
Allison DOC™ for Fleets (3000/4000)
1 From the desktop, click Start then select Programs
4
Allison Transmis-
sion
4
Allison World Transmission Lite.
