- Step 7: Test the Connection to the Vehicle
USB-Link™ Installation and Setup Manual 67
—For wired connection using a USB cable:
• In the Device list, make sure that the heading is USB-Link (Pro-
tocol desired).
• Check to ensure that the connections between the USB-Link™
and PC are secure (i.e., the USB cable).
• Check the connections between the USB-Link™ and the vehicle
(i.e., the Diagnostic Connector).
• Check to make certain that the Power LED on the USB-Link™ is
illuminated.
NOTE:
i For additional information, refer to “Connect the USB-Link™ to a Vehicle”.
5 Click Stop Test to end the test, or select another device to test.
