70 USB-Link™ Installation and Setup Manual
Chapter 3 • Preparing to Use the USB-Link™
The Preferences screen appears.
3 Click on the arrow of the Communication Interface Device drop-down list then
select RP1210 Compliant Device.
4 From the pull down menu, click on the Advanced button.
—Select BT USB-Link J1708 (237) - NEXIQ (NNT, Inc.) for wireless
connection.
—Select USB-Link J1708 (137) - NEXIQ (NNT, Inc.) for wired
connection.
5 Click OK.
6 Click
OK.
NOTE:
i Prior to connecting for the first time, use the NEXIQ Device Tester (refer
to page 65 in this manual) to test the connection to the vehicle for this
device.
Cummins Insite
NOTE:
i Complete the steps in the following procedure before attempting to run this
application.
1 From the PC’s desktop, click
Start then select Programs
4
Intellect
4
Cum-
mins INSITE
.
The application screen appears.
2 Click on
File
4
Connections
4
Add New Connection.
The Connection Wizard screen appears.
3 Click
Next.
The screen prompts you to select a connection type.
4 Click on the radio button (
) for RP1210A.
The screen prompts you to select an RP1210A adapter type.
5 Select USB-Link, for the protocol that you wish to use (i.e., J1708 or J1939).
