This value will be taken from the drive’s analogue input 1 and is scaled for ±4000 to
represent the +/- full scale signal at the input. Refer to the Drive User Guide for
information on the sampling rate of analogue inputs.
This value will be taken from the drive’s analogue input 2 and is scaled for
±1023 to
represent the +/- full scale signal at the input. Refer to the Drive User Guide for
information on the sampling rate of analogue inputs.
This value will be taken from the drive’s analogue input 3 and is scaled for
±1023 to
represent the +/- full scale signal at the input. Refer to the Drive User Guide for
information on the sampling rate of analogue inputs.
This parameter sets the value of analogue output 1. Refer to Pr
91.01 for information on
enabling this parameter
Pr 91.08 Drive analogue input 1 value
Access RO Range ±4000
Default N/A Update Rate 250µs
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Pr 91.09 Drive analogue Input 2 value
Access RO Range ±1023
Default N/A Update Rate 250µs
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Pr 91.10 Drive analogue input 3 value
Access RO Range ±1023
Default N/A Update Rate 250µs
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

Pr 91.11 Drive analogue output 1
Access RW Range ±1023
Default N/A Update Rate NA
Apps Apps Lite Apps Plus Lite V2 ST Plus ST Indexer

