VBA10401-R.3623.A
- Ａ10 ･ -
AF sensor unit
・
Attach 3 screws (#636) with Hexagonal
wrench to screw up but not tight, then give it
about 1 turn counterclockwise.
＃
170×3
＃
636×3
#728
#728
Horizontal lever (#193)
Position for attaching #728
・
Attach #728 so that the FPC of
AF sensor unit can be protected.
FPC
AF sensor unit
#B2163
AF sensor unit
#B2163
