Chapter 4 Setting Up the Microscope
4.2 Setup Procedure
1-91
Attaching the support pillar extension
To attach the TIRF illuminator unit/motorized TIRF illuminator unit/photo activation illuminator unit to the
upper tier, attach the support pillar extension supplied with the stage up kit to the support pillar supplied with
the illuminator unit.
Figure 4.2-30
Support pillar extension
(supplied with the stage up kit)
Support pillar
(supplied with the illuminator unit)
