System Configurations and Part Names
1
1.1 Overview
1.1.1 TIRF Illuminator Unit and Ti-U System Overview
TIRF illuminator unit and Ti-U system overview (front view):
When used in combination with two-laser or three-laser unit
(Standard configuration to use the TIRF illuminator unit)
CAUTION
–
CLASS 3B
LASER RADIATION WHEN OPEN AVOID EXPOSURE TO THE BEAM
Figure 1.1-1
* For details, see Section 8.1, “Overall Configuration,” in Chapter 8, “Specifications and Performance.”
(1) Power supply devices for the laser devices
(2) Laser unit (C-LU2, C-LU3, C-LU3EX)
(3) PC
(4) Optical fiber
(5) TI-LUSU shutter unit
(6) AC adapter for the shutter unit
(7) TV camera (video camera)
(8) TI-FLC epi-fl filter turret
(9) Power supply device for the diascopic illumination
(10) TIRF illuminator unit
(11) HG fiber light source
(12) Laser safety cover
(13) Interlock cable
(1)
(5)
(7)
(10)
(3)
(2)
(4)
(6)
(9)
(11)
(8)
(12)
(13)
