Nikon Eclipse TI-TIRF-E User Manual

Chapter 1 System Configurations and Part Names
1.1 Overview
1-5
TIRF illuminator unit and Ti-U system overview (top view):
When used in combination with two-laser or three-laser unit
CAUTION
–
CLASS 3B
LASER RADIATION WHEN OPEN AVOID EXPOSURE TO THE BEAM VORSICHT
–
LASERSTRAHLUNG
KLASSE 3B, WENN ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN
CAUTION
–
CLASS 3B
LASER RADIATION WHEN OPEN AVOID EXPOSURE TO THE BEAM
SER RADIATIO
OID EXPOSU
CLASS 3B LASE
AVOID EXPOSURE
LASER LIGHT IS EMITTE
FROM
OBJECTIVE APERT
RS-232C LASER UNIT
TI-LUSU
INPUT
1A
POWER
SAFETY
COVER
CLOSE
BINO
CLOSE
12V
LASER SHUTTER
Exclusive use for TI
-
TIRF system
Don't use this unit with other systems.
Figure 1.1-2
* For details, see Section 8.1, “Overall Configuration,” in Chapter 8, “Specifications and Performance.”
(1) Power supply devices for the laser devices
(2) Laser unit (C-LU2, C-LU3, C-LU3EX)
(3) PC
(4) Optical fiber
(5) TI-LUSU shutter unit
(6) AC adapter for the shutter unit
(7) TV camera (video camera)
(8) TI-FLC epi-fl filter turret
(9) Power supply device for the diascopic illumination
(10) TIRF illuminator unit
(11) HG fiber light source
(12) Laser safety cover
(13) Interlock cable
(1)
(4)
(6)
(7)
(10)
(3)
(2)
(5)
(9)
(11)
(8)
(12)
(13)
