Chapter 1 System Configurations and Part Names
1.1 Overview
1-14
1.1.4 TI-PAU Photo Activation Illuminator Unit and Ti-U System Overview
Photo activation illuminator unit and Ti-U (front view):
When used in combination with two-laser or three-laser unit
(Standard configuration to use the photo activation illuminator unit)
CAUTION
–
CLASS 3B
LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO THE BEAM
Figure 1.1-11
* For details, see Section 8.1, “Overall Configuration,” in Chapter 8, “Specifications and Performance.”
(1) Power supply devices for the laser devices
(2) Laser unit (C-LU2, C-LU3, C-LU3EX)
(3) PC
(4) Optical fiber
(5) TI-LUSU shutter unit
(6) AC adapter for the shutter unit
(7) TV camera (video camera)
(8) TI-FLC epi-fl filter turret
(9) Power supply device for dia illumination
(10) Photo activation illuminator unit
(11) HG fiber light source
(12) Interlock cable
(4)
(5)
(9)
(11)
(10)
(3)
(8)
(6)
(7)
(1)
(2)
(12)
