Chapter 8 Specifications and Performance
8.1 Overall Configuration
1-232
Unit Device Model name Remarks
Two-laser unit C-LU2
Three-laser unit C-LU3
Three-laser unit EX C-LU3EX
Laser unit
Four-laser module A LU4A
See Table 8.1-3 for mountable lasers.
Filter slider cover
Filter cube port cover
retaining plate
Safety label
Ti laser safety kit
Protection plate for
nosepiece
8.1.2 Motorized TIRF Illuminator Unit ― Configuration for N-STORM
Table 8.1-2
Unit Device Model name Remarks
Ti
Ti-E
Ti-E/B
Use the TI-DH Dia Pillar Illuminator
100W.
Apo TIRF 100 × H/1.49
Objective for TIRF
microscopy
Plan Apo VC 100 × H/1.4
Select the appropriate objective for
observations.
Shutter unit TI-LU4SU For the four-laser module A
AC adapter EA1050E-120
Epi fl-filter turret
TI-FLC-E
TI-FLC-E/HQ
Use the N-STORM filter cube.
Microscope and
accessories
Epi illumination lamp
and power supply
device
Make sure to read the instruction
manuals for the products.
TIRF TI-TIRF-E
TIRF illuminator
Optical fiber C1 single mode fiber
3D-STORM port
Allows the cylindrical lens to be
inserted or removed. For microscopy
other than 3D-STORM microscopy,
remove the cylindrical lens from the
optical path.
DSC support columns
Ti-E fixing plates
STORM slider
This slider can be inserted or removed.
For microscopy other than N-STORM
microscopy, perform microscopy with
the slider lifted (with the lens removed
from the optical path).
N-STORM kit N-STORM kit parts
Lambda plate slider
This slider can be inserted or removed.
For microscopy other than N-STORM
microscopy, perform microscopy with
the slider extracted toward you (with
the filter removed from the optical
path).
To Next Page
