Chapter 5 Laser Unit
5.2 C-LU2 Two-laser Unit, and C-LU3 Three-laser Unit
1-105
NOTE:
Leave the lasers turned on for approximately 10 minutes before adjusting. Making adjustments
immediately after turning on the lasers may result in shifts from adjusted levels.
Two-laser unit
Three-laser unit
Figure 5.2-2
