Chapter 5 Laser Unit
5.5 Setting Up the LU-LR Four-laser PS Rack
1-199
Components (accessories included)
1. LU-LR four-laser PS rack
Figure 5.5-1
2. Clamp for laser power supplies
Figure 5.5-2
Figure 5.5-3 Figure 5.5-4
[1] For Ar laser [2] For HeNe laser
[3] For laser diodes and DPSS
laser
Figure 5.5-5
[4] For previous laser diode
(till March 2007)
3. Interlock jumper connector
Figure 5.5-6
x 2 x 1 x 4
