Chapter 8 Specifications and Performance
8.1 Overall Configuration
1-236
Type Device Laser specifications
Mountable unit and
position
HeNe laser
(green)
Manufacturer: Melles Griot
Head: 05LGP193
Power supply: 05LPL951-065: for 100V
05LPL915-065: for 115/230V
543.5 nm (1 mW)
C-LU2 (L2)
C-LU3 (L3)
C-LU3EX (L3)
LU4A (L4)
Solid-state laser
(yellow)
Manufacturer: Melles Griot
Head: 85YCA series (85YCA010,
85YCA020, 85YCA025)
Power supply: 85YCA series (supplied)
561 nm (10, 20, 25 mW)
C-LU2 (L2)*
1
C-LU3 (L3)*
1
C-LU3EX (L3)*
1
LU4A (L4)
HeNe laser
(yellow)
Manufacturer: JDS UNIPHASE
Head: 1677P
Power supply: 1207-3/100V
1207-1/115V
1207-2/230V
594 nm (2 mW)
C-LU2 (L2)
C-LU3 (L1)
C-LU3EX (L1)
Manufacturer: JDS UNIPHASE
Head: 1125P
Power supply: 1202-3/100V
1202-1/115V
1202-2/230V
633 nm (5 mW)
C-LU2 (L2)
C-LU3 (L1, L3)*
2
C-LU3EX (L1, L3)*
2
HeNe laser
(red)
Manufacturer: Melles Griot
Head: 56 ICS 272
Power supply: 56 IMA 015/018/019
635 nm (3 mW)
C-LU2 (L2)*
1
C-LU3 (L1)*
1
C-LU3EX(L1)*
1
Manufacturer: Melles Griot
Head: 56 ICS series (56ICS/S2669)
Power supply: 56 IMA series
(56IMA022)
638 nm (10 mW)
C-LU2 (L2)*
1
C-LU3 (L1)*
1
C-LU3EX (L1)*
1
LU4A (L1)
Diode laser
(red)
Manufacturer: Coherent
Head: CUBE series (CUBE640)
Power supply: CUBE series
640+2/-5 nm (40 mW) LU4A (L1)*
1
*1: A laser adapter is required for attachment.
*2: When the mounting position is set to L3, the transmittance becomes 20% to 30%.
