Chapter 1 System Configurations and Part Names
1.1 Overview
2-4
TIRF-PAU illuminator and Ti-E system overview (top view)
Figure 1.1-2
* For details, see Section 8.1, “Overall Configuration,” in Chapter 8, “Specifications and Performance.”
(1) Power supply devices for the laser devices
(2) LU4A four-laser module A (with LU4-B5
Beamsplitter 50/50 installed)
(3) PC
(4) Optical fiber (for TIRF)
(5) Optical fiber (for PAU)
(6) TI-LU4SU shutter unit LU4
(7) TV camera (video camera)
(8) TI-FLC-E/HQ motor epi-fl filter turret
(9) Power supply device for the diascopic
illumination
(10) Hub controller A
(on the microscope back, with AC adapter)
(11) TIRF-PAU illuminator
(12) HG fiber light source
(13) Remote control pad
(14) Laser safety cover
(15) Interlock cable
(16) USB cable
(1)
(2)
(4)
(6)
(7)
(11)
(3)
(9)
(8)
(14)
(12)
(13)
(16)
(5)
(15)
(10)
