Chapter 4 Setting Up the Microscope
4.1 List of Parts
1-73
Photo activation illuminator unit
Table 4.1-2
Unit Name of equipment Model Remarks
Ti-E
Ti-E/B
Ti-U
Ti
Ti-U/B
Use with the TI-DH dia-illuminator
100W.
TI-LUSU
Shutter Unit
TI-LU4SU
PC compatible
AD-1260B
AC adapter
EA1050E-120
For TI-LUSU shutter unit
TI-FLC
TI-FLC-E
Epi-fl filter turret for
epi-fl illumination
TI-FLC-E/HQ
Fiber optic light source
Episcopic light source
Lamphouse + power
supply
Make sure to read the instruction
manuals for the product.
26
Stage ring
32
32 is made of glass.
Stage up kit TI-BSUK70
Microscope and
accessories
Back port unit TI-BPU
TI-BSUK70 70 mm stage up kit is
required.
Photo activation
illuminator unit
TI-PAU
Switches PA-GFP/EPI. Requires an
optical path switch mirror.
Photo activation
illuminator unit
Fiber C1 single mode fiber
PC Commercially-available PC
Monitor
Commercially-
available monitor
PA-GFP image
observation
TV camera
Commercially-
available TV camera
An adapter is required for connection
to the microscope port.
Two-laser unit C-LU2
Three-laser unit C-LU3
Three-laser unit EX C-LU3EX
Laser Unit
Four-laser module A LU4A
See “Chapter 5 Laser Unit” for details
on which lasers can be mounted.
Filter slider cover
Filter cube port cover
retaining plate
Safety label
Ti laser safety kit
Protection plate
