Nikon Eclipse TI-TIRF-E User Manual

Chapter 4 Setting Up the Microscope
4.2 Setup Procedure
1-83
On the laser safety cover (TIRF illuminator unit or motorized TIRF illuminator unit)
Make sure that the following three warning labels at the rear left, when viewed from the Binocular
eyepiece tube: “(1) IEC warning label - laser hazard symbol”, “(2) IEC explanatory label - Class 3B
laser product”, and “(8) IEC aperture label 1” is affixed.
LASER RADIATION
AVOID EXPOSURE TO BEAM
CLASS 3B LASER PRODUCT
AVOID EXPOSURE
LASER LIGHT IS EMITTED
FROM
OBJECTIVE APERTURE
Figure 4.2-17
Top surface of stage (photo activation illuminator unit)
Make sure that the following three warning labels at the rear left, when viewed from the Binocular
eyepiece tube: “(1) IEC warning label - laser hazard symbol”, “(2) IEC explanatory label - Class 3B
laser product”, and “(8) IEC aperture label 1” is affixed.
LASER RADIATION
AVOID EXPOSURE TO BEAM
CLASS 3B LASER PRODUCT
AVOID EXPOSURE
LASER LIGHT IS EMITTED
FROM
OBJECTIVE APERTURE
Figure 4.2-18
(8)
(2)
(1)
Laser
safet
y
cove
r
(8)
A
bout 5 mm
About 5 mm
About 5 mm
(2)
(1)
Stage top surface
A
bout 5 mm
Stage top surface
