Nilfisk-Advance Advance SC250

03 - General Information
11
Service Manual – SC250, Scrubtec 334, MA 30
Machine Nomenclature (Continues)
Figure 3
Recovery tank
cover
Tanks (solution and
recovery water)
container
Machine body/cleaning
deck
Brush engagement/dis-
engagement lever
Brush oor pressure
regulation knob
Park pedal lifted: for
washing/drying
Park pedal pressed: for
parking/movement
Front wheels
Tanks container
lifting handle
Handlebar with
control panel
