40 - Recovery System 88Service Manual – SC250, Scrubtec 334, MA 30
Air Filter, Gaskets and Recovery Water Duct Cleaning
1. Remove the tanks container from the machine body using the handle.
2. Remove the air lter (A) and clean it.
3. Ret the lter in the housing of the gasket (B).
Note: The gaskets (B) and (C) allow the creation of the vacuum in the system which is
necessary to collect the recovery water.
4. Check and clean the gasket (B) of the vacuum system motor.
5. Check and clean the recovery water duct gasket (C).
Figure 5
B
A
C
