40 - Recovery System 86Service Manual – SC250, Scrubtec 334, MA 30
Component Locations
• Recovery tank assembly
• Vacuum sleeve from squeegee
• Vacuum sleeve from grid with automatic shut-off
oat
• Recovery tank cover
• Cover gasket
• Vacuum grid with automatic shut-off oat
• Vacuum system motor (M2)
• Vacuum system motor gasket
• Vacuum system motor lter
Figure 2
Vacuum system motor (M2)
Figure 3
Cover gasket
Recovery tank assembly
Vacuum sleeves
Recovery tank cover
Vacuum system
motor gasket and
lter
Vacuum grid with
automatic shut-off oat
