14 - Wheel System, Non Traction 39Service Manual – SC250, Scrubtec 334, MA 30
14 - Wheel System, Non Traction
Functional Description
The wheels assembly is composed by a pair of pivoting rear wheels and a pair of front wheels.
The front axle is tted with a pedal mechanism for moving and parking the machine with the brush and squee-
gee assembly lifted from the oor.
Component Locations
• Pivoting rear wheels
• Front wheels
• Machine lifting front axis
• Movement/parking - washing/drying pedal
Figure 1
Movement/parking -
washing/drying pedal
Machine lifting
front axis
Pivoting rear
wheels
Front wheels
