34 - Scrub System 66Service Manual – SC250, Scrubtec 334, MA 30
Maintenance and Adjustments
Brush and Brush Compartment Cleaning
1. Ensure that the machine is off.
2. Remove the tanks container from the machine body using the handle.
3. Lift the machine body to access the lower part of the cleaning deck.
4. Turn the lever counter-clockwise (A) and remove the brush.
5. Clean and wash the cylindrical brush with water and detergent.
6. Check the brush bristles for integrity and wear; if necessary, replace the brush.
7. Carefully clean the brush compartment (B).
8. Remove the debris collection tank (C), clean it and rinse it with clean water, then put it back in its seat.
9. Reinstall the cylindrical brush on the drive hub (D) and engage it by turning the lever (E) clockwise.
Figure 4
E
A
B
D
C
