Nilfisk-Advance Advance SC250

34 - Scrub System 75Service Manual – SC250, Scrubtec 334, MA 30
Specications
Description / Model
Advance SC250, Clarke MA 30
Nilsk SC250, Scrubtec 334
Cleaning width 13.4 in (340 mm)
Cylindrical brush diameter 3 in (80 mm)
Brush pressure on the ground Max 26 lb (Max 12 Kg)
Brush motor technical data
Power 0.24 hp (180 W)
Nominal speed 2000 ± 140 rpm
Nominal current draw 7 ± 0.7 A
Nominal torque 0.88 Nm
No-load current 0.5 ± 0.3 A
No-load speed 2450 ± 172 rpm
Insulation class B
IP rating IP20
Conductor and insulation materials UL certied
Brush rotation speed 1,000 rpm
