10 - Chassis System 38Service Manual – SC250, Scrubtec 334, MA 30
10 - Chassis System
Chassis (main parts)
Reference to Figure 1
• Plastic tank support chassis, solution system and recovery water system
• Metal handlebar support chassis
Plastic tank support chassis,
solution system and
recovery water system
Metal handlebar support
chassis and battery housing
Figure 1
