34 - Scrub System 71Service Manual – SC250, Scrubtec 334, MA 30
Driving Belt (continues)
Replacement
8. If the belt (C) requires replacement, loosen the 3 screws (F) and move the brush motor and pulley (G) to
loosen the belt, then replace it.
9. Tension the belt (see the procedure given above).
Figure 9
C
F
F
F
F
G
G
F
F
Reassembly
10. Perform steps 1 to 4 in the reverse order.
