61
– Enter STA PIN: If you select it, you need to enter the station PIN from client.
– Use AP PIN: The PIN is generated by AP.
Push button configuration (PBC), an actual push button on the hardware or through a simulated push
button in the software. (This is an optional method on wireless client).
If you are using the PIN method, you will need a Registrar (access point/wireless router) to initiate the registration between
a new device and an active access point/wireless router. (Note: The PBC method may also need a Registrar when used in a
special case where the PIN is all zeros).
In order to use the push-button for WPS authentication, you must ensure that the network card supports the function. If
yes, no configuration is needed. You can press the WPS button directly to enable the WPS function.
Manual Setup AP
This page provides 9 types of network authentication modes, including Open, Shared, 802.1X, WPA, WPA-PSK, WPA2,
WPA2-PSK, Mixed WPA2/WPA, and Mixed WPA2/WPA-PSK.
Open/Shared Mode
Select SSID: Select a SSID for configuring the security settings.
Network Authentication: Select the Open mode.
WEP Encryption: Enable or disable WEP encryption. After enabling this function, you can set the encryption strength,
current network key, and network keys.
Encryption Strength: You can set 64-bit or 128-bit key.
Current Network Key: The current key that you use.
Network Key1/2/3/4: Set the network key. If it is 128-bit key, you need to enter 13 ASCII characters or 26
hexadecimal digits. For the 64-bit key, you need to enter 5 ASCII characters or 10 hexadecimal digits.
