NLB 1012D - Page 194

Revision 9
~
' \ .
For stuffing box oiler fittings order part
no. PM12330
A- Cylinders High Pressure Pump Fluid End
-~-~ tHorizontal Spacer
D tVertical Spacer
t: Additional Items used in the 1012D High Efficiency unit with 1" plungers.
© Copyright August, 2004 NLB Corporation
9-6
