Nokia ONT - Figure 8-4 WAN Status Page; Table 8-3 WAN Status Parameters

Configure
a
G
-
2426G
-
B
indoor
ONT
Viewing device information and connection status
Viewing WAN status
Nokia
ONT
3FE-49441-ABAA-TCZZA
June
2021
Issue 1
103
Figure 8-4 WAN Status page
Table 8-3 WAN Status parameters
Field Description
WAN Connection List Drop-down menu listing all WAN connections. The connection shown is the connection for which
WAN status will be shown.
MPTCP Status Enables or disables the MPTCP status
Connection Mode Connection mode of the WAN connection
Enable/Disable Select this checkbox to enable or disable the WAN connection
VLAN VLAN ID
WAN Link Status Indicates whether the WAN link is up or down
IPv4 Address IP Address of the ONT
Netmask Network mask
Gateway Gateway address
Primary DNS Primary Domain Name Server
Second DNS Secondary Domain Name Server
Manual DNS Manual Domain Name Server
PON Link Status Whether the PON link is up or down
