G-2426G-B GEM ports and T-CONTs
Nokia
ONT
3FE-49441-ABAA-TCZZA
June
2021
Issue 1
62
Table 5-11 G-2426G-B, dimension data specifications (continued)
Dimension Specification
number of supported beacons /APs in a mesh —
number of supported WAN interfaces 8
number of supported VLANs 4094
number of Tconts and GEM ports in the ONTs 32 Tconts / 256 GEM ports
number of LLIDs in the ONTs —
number of priority queues, overall buffer size 128, Max 16MB for WAN and 4MB for LAN
number of multicast groups (DACL entries) 1024
5.8 G-2426G-B GEM ports and T-CONTs
Table 5-12, “G-2426G-B indoor ONT capacity for GEM ports and T-CONTs” (p. 62) lists the
maximum number of supported T-CONTs and GEM ports. See the appropriate release Customer
Release Notes for the most accurate list of supported devices.
Table 5-12 G-2426G-B indoor ONT capacity for GEM ports and T-CONTs
ONT or MDU Maximum Notes
Package P ONTs
GEM ports per indoor or outdoor ONT 256
256 are present; 254 are available, and 2 are reserved for
multicast and debugging
T-CONTs per indoor or outdoor ONT 32 32 are present; 31 are available, and 1 is reserved for
OMCI
5.9 G-2426G-B performance monitoring statistics
The following section identifies the supported performance monitoring statistics for G-2426G-B
ONTs. A check mark indicates the statistic is supported on that ONT. An empty cell indicates the
statistic is not supported. The following tables are categorized by supported alarm types:
• Table 5-13, “Package S ONTs ONTENET performance monitoring statistics” (p. 63) provides
statistics for ONTENET type counters
• Table 5-14, “Package S ONTs ONTL2UNI performance monitoring statistics” (p. 63) provides
statistics for ONTL2UNI type counters
• Table 5-15, “Package S ONTs PONONTTC, PONONTMCTC, PONONTTCHSI,
PONONTTCCES, PONONTTCFLOW, PONONTTCVOIP performance monitoring statistics”
(p. 63) provides statistics for PONONTTC, PONONTMCTC, PONONTTCHSI, PONONTTCCES,
PONONTTCFLOW, and PONONTTCVOIP type counters
• Table 5-16, “Package S ONTs PONONTTC aggregate performance monitoring statistics” (p. 64)
provides statistics for PONONTTC aggregate type counters
