Nokia ONT - Figure 8-46 Port Forwarding Page; Table 8-36 Port Forwarding Parameters

Configure
a
G
-
2426G
-
B
indoor
ONT
Configuring the Application
Configuring port forwarding
Nokia
ONT
3FE-49441-ABAA-TCZZA
June
2021
Issue 1
170
Figure 8-46 Port Forwarding page
2
Configure the following parameters:
Table 8-36 Port Forwarding parameters
Field Description
Application Name Select an application name from the list.
The default is Custom settings.
WAN Port Enter the WAN port range.
LAN Port Enter the LAN port range.
Internal Client Select a connected device from the list and enter the associated IP address.
Protocol Select the port forwarding protocol from the list:
• TCP
• UDP
• TCP/UDP
Enable Mapping Select this checkbox to enable mapping.
WAN Connection List Select a WAN connection from the list.
Note: Only active devices are shown on this list.
