3FE-49441-ABAA-TCZZA
Issue 1
Network configuration
Configuring WAN DHCP
Table 8-14 WAN network parameters—Bridge Mode
Field Description
WAN Connection List Choose a WAN connection from the drop-down menu to set the connection parameters
Connection mode This option is only available for the operator ID MSNA, and for some operator-specific operator IDs.
Choose a connection mode: Bridge Mode.
Enable/Disable Select this checkbox to enable the WAN connection.
Service Select this checkbox only if this domain provides IPTV service.
Enable VLAN Select this checkbox to add a VLAN tag. If this box is selected, you can add a VLAN number.
VLAN Mode Select a VLAN mode from the drop-down menu.
LAN Port binding Select a LAN port or ports that are associated with this bridge domain: LAN1, LAN2, LAN3, LAN4, or
LAN5.
These ports are bridged to the network over the same VLAN when it is added. Port-to-port
communication is permitted within the domain.
SSID Port binding Select a SSID port or ports that are associated with this bridge domain: SSID1, SSID2, SSID3, SSID4,
SSID5, SSID6, SSID7, or SSID8.
These ports are bridged to the network over the same VLAN when it is added. Port-to-port
communication is permitted between devices associated with SSIDs or connected to LAN ports within
the domain.
3
Click Saveto save the configuration.
Click Delete to delete the configuration.
E
ND OF
STEPS
8.20 Configuring WAN DHCP
1
Click Network→WAN DHCP from the left pane in the GPON Home Gateway page. The WAN
DHCP page displays.
