Table 8-8 Optics Module Status parameters
Field Description
Laser Bias Current (ONT ANI-ONT-Side Optical Measurements) Laser bias current, measured in uA Optics
Module Voltage (ONT ANI-ONT-Side Optical Measurements) Optics module voltage, measured in V
Optics Module Temperature (ONT ANI-ONT-Side Optical Measurements) Optics module temperature, measured in C
Rx Optics Signal Level at 1490 nm (ONT ANI-ONT-Side Optical
Measurements)
Received optics signal level at 1490 nm, measured in
dBm
Tx Optics Signal Level at 1310 nm (ONT ANI-ONT-Side Optical
Measurements)
Transmitted optics signal level at 1310 nm, measured in
dBm
Lower (ONT ANI-ONT-Side Optical Measurements-Optical Threshold) Lower optical threshold, measured in dBm
Upper (ONT ANI-ONT-Side Optical Measurements-Optical Threshold) Upper optical threshold, measured in dBm
2
Click Refresh to display up-to-date information.
E
ND OF STEPS
8.14 Viewing statistics
1
Click Status→Statistics from the left pane in the GPON Home Gateway page.
Select the LAN tab, WAN tab or WLAN tab to view the respective ports.
