Network configuration
Configuring wireless scheduling
3FE-49441-ABAA-TCZZA
Issue 1
Table 8-17 Wireless (5GHz) parameters (continued)
Field Description
Create One New Domain Select this checkbox to create a new domain.
WAN Interface Select a WAN interface from the list.
Number of IP Select the number of IPs connected to the domain.
LAN List Select one or more checkboxes.
3
By default the WPS is enabled in SSID5, if you want to enable it in a different SSID, disable it
first from SSID5.
1. Go to the SSID5, and in the field Enable WPS select Disable.
2. Return to the SSID of your choice and in the field Enable WPS select Enable.
3. Save your configuration.
4. Click WPS Connect.
5. Connect to this SSID all the necessary devices using the WPS button or entering the PIN in
the devices.
6. When all desired devices have been connected, return to the WebGUI, select disable in the
Enable WPS field and click Save at the bottom of the menu.
7. Select SSID5 in the SSID Select field, and enable the WPS in the field Enable WPS
8. Click Save.
9. If desired, click WPS connect.
E
ND OF
STEPS
8.23 Configuring wireless scheduling
1
Click Network→Wireless Schedule from the left pane in the GPON Home Gateway page. The
Wireless Schedule page displays.
