Nokia RM-506 - Flash Concept with FPS-21

Type Description
XCS-4 Modular cable
CA-35S Power cable
USB cable
CU-4 flash concept with FPS-21
Figure 4 CU-4 flash concept with FPS-21
Type Description
Product specific devices
FS-102 Flash adapter
Other devices
CU-4 Control unit
FPS-21 Flash prommer box
PKD-1/PK-1 SW security device
SS-62 Flash adapter base
SX-4 Smart card
PC with Phoenix service software
Cables
PCS-1 Power cable
RM-505; RM-506
Service Tools and Service Concepts
