Type Description
PC with VPOS and Phoenix service software
Measurement equipment
Cables
PCS-1 DC power cable
XCS-4 Modular cable
XRS-6 RF cable
CA-128RS RF tuning cable
USB cable
GPIB control cable
Module jig service concept with SB-6
Figure 11 Module jig service concept with SB-6
RM-505; RM-506
Service Tools and Service Concepts
Page 2 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2009 Nokia. All rights reserved.
