Specifications
Specifications
116 117
8. Specifications
Phase 22 Synthesis Engine
• 2 Oscillators (sine wave, phase modulation, frequency randomization)
• 2 Shapers (sine curve, adjustable foldback and asymetry)
• Ring Modulator
• Comb Filter (tunable, with allpass and lowpass)
• State Variable Filter (multi-mode, 2-4 poles, FM)
• Feedback Mixer (4 input signals, shaper for the sum)
• Feedback bus with 4 destinations
• Output Mixer (stereo, 4 input signals, shaper for the sum)
• 5 Stereo Eects: Phaser/Flanger/Chorus, Cabinet (amp simulation),
8-pole Gap/Band Filter, Echo, Reverb
• 3 ADBDSR Envelopes, adjustable attack curve
• Velocity sensitivities for envelope levels, attack times, and release times
• 4 Macro Controls, assignable to up to 86 target parameters
• 8 Hardware Sources, mappable to the 4 Macro Controls
• Number of parameters: 328
• Resolution of the parameters: typically 1000 steps (250 ... 15000 steps)
• Resolution of key velocity, ribbons, bender, aertouch, pedals: 4000 steps
• 20-voice polyphony, variable Unison settings
• Scale parameters for micro-tuning the 12 steps of the octave
Hardware Features
• 61-key (5 octave) Fatar keybed with semi-weighted long-arm keys
• Note-on and note-o velocity sensitivity
• Monophonic aertouch
• Two 800 mm touch strips (ribbons), each with 33 LED dots
• Ribbon modes: absolute, relative, combinable with return-to-center
• Lever (magnetic force loaded) for pitchbending and similar applications
• Control panel with an OLED display (128 x 32 dots) and four buttons
• Output volume potentiometer (at the front)
• Headphone level potentiometer (at the front)
• The Base Unit can be used without the Panel Unit
• Magnetic front panel foils replaceable to support future synthesis engines
Parameter Editing
• 4 Selection panels, each with 24 buttons and LEDs
• Labeling by exchangeable magnetic overlays
• Edit panel with an OLED display (256 x 64 dots), incremental encoder and 18 buttons
• The ribbons are also assignable for parameter editing.
• User-definable Init preset and Default values
• Randomize function
• Graphical User Interface on any WiFi-enabled device running a browser,
unique zoom-and-pan navigation, enabled for touch
Preset System
• User-definable banks
• Unlimited number of presets per bank
• User-editable infos per preset
• Search function to find presets by name or tags in the infos
• Morphing transition between presets.
Undo System
• Unlimited undo for all user interactions, including sound editing steps
• Undo list with support for dierent editing branches (tree view)
Connectors
• Main audio outputs (L, R) (TRS, balanced by transformers)
• Headphone output at the front (TRS)
• 4 inputs for analog controls, such as pedals (TRS, flexible pin-assignment)
• USB host connector for data exchange and soware updates
Dimensions
• Base Unit only: 900 x 290 x 100 mm (width x depth x height)
• Including Panel Unit: 900 x 410 x 160 mm (width x depth x height)
Weight
• Base unit: 10.5 kg
• Panel Unit: 3 kg
