68 Product Specications
2583703_EN_1608 Nortec GS
Figure 36:
55.5
(1410)
27.7
(705)
1.6
(42)
1.0
(25)
3.5
(89)
51.5
(1309)
39.7
(1009)
7.8
(199)
5.8
(148)
25.1
(638)
4.3
(108)
Steam Outlet
3 in (75 mm)
ø
Gas Inlet
3/4 in NPT
Power In
3/4 in (19 mm)
ø
Condensate Outlet
(CS/NX only)
1/2 in (13 mm)
ø
Drain Outlet
7/8 in (23 mm)
ø
27.0
(684)
3.2
(80)
18.7
(474)
11.6
(295)
12.7
(322)
8.6
(219)
Water Inlet**
3/4 in BSPP
23.7
(603)
1.5
(37)
Exhaust Outlet*
80 mm - GS 150-CS/NX
ø
* Metric to imperial size adaptor supplied with unit
** BSPP to NPT adaptor supplied with unit
Air Inlet
3 in (75 mm)
ø
Nortec GS 150
