8 Getting to know the projector
8.1 Projector chassis
Item Number
Description
1
Projector Lens Holder with lens-lid
2
IR Receiver Front
3
Keypad & LCD
4
Video & I/O Connections
5
IR Receiver Rear
6
Air Intakes (front & front sides)
7
Adjustable Feet (Qty 4) - 1 per corner
8
Mains Power Inlet Connector
9
Projector Air Exhaust
A range of interchangeable lens options is available separately. Specifying the correct lens for the intended
application is the responsibility of the purchaser.
