Fig. 1 - Single projector synchronous input Fig. 2 - Dual projector synchronous input
NOTE! - Failure to Sync / Genlock the IG’s properly may result in on screen image artefacts or
the image not being displayed at all.
Recommended projector setup / workflow procedure is as follows:
• Select DVI-1 as Source.
• Go to the Installation menu and select 1920x1200@60/2560x1600@60*¹ as Edid for both DVI-1
and DVI-2.
• Go to Picture menu and select Dual input mode - sequential.
• Select DVI-1&2 as Source.
• Go to Picture menu and select 3D. Toggle Swap eyes if necessary and adjust Glasses sync delay
for best effect.
*¹ - P1 projector model variant native resolution dependent.
Video frame/video timing information is as illustrated below:
