Dual input mode determines how the video frame is compiled. Options are:
• sequential: A whole video frame is displayed sequentially (i.e. in order, one video frame after
another).
• top/bottom: The video frame is compiled using two separate video inputs each displaying
2560x800@120Hz resolution using Dual Head mode (DVI-1&2). In this mode of operation DVI-1
provides the bottom half of the video frame, whilst DVI-2 provides the top half.
The default setting is sequential.
8.10.2 Source Menu
You can select between DVI-1, DVI-2 or both DVI-1&2 (aka dual-head). DVI-1&2 is used for 120Hz
applications, like
• 2x60Hz stereoscopic with one left eye and one right eye channel
• 120Hz mono
• Day/night and dusk/dawn simulation. Where one channel is for daylight and the other is for
night (infrared). In this case, DVI-1 is dedicated to RGB (daylight) and DVI-2 to IR.
8.10.3 Install Menu
Network provides standard network configuration options.
Network sub menu features include:
DHCP (Dynamic Host Configuration Protocol) can be enabled or disabled. The default is enabled.
When enabled, the IP address is automatically assigned. When disabled, the IP address is set
manually.
Network: >
Image orientation: desktop front
Indicators: enabled
RGB LED power: 100
Diagnostics: >
Test pattern: none
Lens motors: enabled
Service: >
OSD status enabled
Projector ID 0
IR remote receivers: both
OSD transparency: enabled
OSD placement: left
DP edid: WQXGA@60
DVI1 edid: WQXGA@60
DVI2 edid: WQXGA@60
DHCP: enabled
IP address: 192.168.001.023
Subnet mask: 255.255.255.000
Default gw: 192.168.001.019
HW addr: F8_DC-7A-0B-D4-09
