Desired mode can be enabled or disabled. When enabled, Desired values are used as color
space. When Desired is disabled, Measured values are used as color space. The default setting
varies according to ordered product specification.
NOTE! Projectors ordered with Factory Colour Matching are shipped with Desired mode
enabled. All others are shipped with it disabled.
Factory default resets Measured and Desired values to their original factory readings. The user is
prompted to confirm this action prior to completing the task.
Smear Reduction is a method to reduce the smearing-effect in fast panning applications. Applying smear
reduction will reduce the brightness of the image and reduce the frame refresh rate. You can select
between none, 2 ms, 4 ms, 6 ms, 8 ms and black frame smear reduction.
Scaling Mode options are one to one, fill aspect & fill all add text. The default setting is one to one.
Dual Input Mode options are sequential, top/bottom add text. The default setting is sequential.
Frame lock allows video frame lock to the input source for the purpose of fault diagnosis to be enabled
or disabled. The default setting is enabled.
Scaling mode allows different aspect ratio’s to be selected. Options are:
• one to one: The input resolution is centered on the imaging device and mapped pixel by pixel.
Scaling is disabled.
• fill aspect: The input resolution fills the imaging device horizontally and/or vertically whist
maintaining aspect ratio.
• fill all: The input resolution fills the entire imaging device regardless of input resolution / aspect
ratio.
The default setting is one to one.
